Aluminium Grade 2017 Plate
- Home
- Aluminium Grade 2017 Plate
Aluminium Grade 2017 Plate is a high-strength alloy known for its excellent machinability and exceptional mechanical properties. This alloy is primarily used in applications requiring high strength-to-weight ratios and excellent resistance to fatigue. Triumph Metallic Overseas is a leading manufacturer, supplier, stockist, and exporter of Aluminium Grade 2017 Plates, catering to various industries including aerospace, automotive, and structural engineering.
The Aluminium Grade 2017 Plate is characterized by its outstanding mechanical properties, including high tensile strength and good resistance to corrosion. This alloy is particularly well-suited for applications where weight reduction is crucial without compromising structural integrity. With Triumph Metallic Overseas, customers can rely on the consistent quality and performance of our Aluminium Grade 2017 Plates, ensuring they meet stringent industry standards.
Due to its robust properties, Aluminium Grade 2017 Plate finds extensive applications across multiple sectors. In the aerospace industry, it is often used in aircraft structures, fuselage components, and other critical parts that require lightweight yet strong materials. The automotive sector also benefits from this alloy in manufacturing components that enhance performance and fuel efficiency. Triumph Metallic Overseas supplies Aluminium Grade 2017 Plates that meet the specific requirements of these industries, ensuring reliability and safety in every application.
Aluminium Grade 2017 Plate Specifications
| Property | Specification |
|---|---|
| Alloy | 2017 |
| Temper | T451 |
| Thickness | 0.8 - 200 mm |
| Width | Up to 2000 mm |
| Length | Up to 6000 mm |
| Density | 2.8 g/cm³ |
| Tensile Strength | 480 MPa (min) |
| Yield Strength | 390 MPa (min) |
| Elongation | 4% (min) |
| Thermal Conductivity | 120 W/m·K |
| Electrical Conductivity | 30% IACS |
| Corrosion Resistance | Good |
Aluminium Grade 2017 Plate Equivalent Grades
| Aluminium Grade 2017 | Equivalent Grades |
|---|---|
| 2017A | AA2017 |
| 2017B | AA2017 |
| 2017T4 | AA2017 |
| 2017T6 | AA2017 |
| AlCu4PbMg | EN AW-2017 |
| 2017A-T4 | EN AW-2017 |
| 2017A-T6 | EN AW-2017 |
Aluminium Grade 2017 Plate Chemical Composition (%)
| Element | Symbol | Composition (% Weight) |
|---|---|---|
| Aluminium | Al | 90.0 - 94.0 |
| Copper | Cu | 3.5 - 5.0 |
| Manganese | Mn | 0.4 - 0.9 |
| Silicon | Si | 0.5 Max |
| Iron | Fe | 0.5 Max |
| Magnesium | Mg | 0.2 - 0.6 |
| Zinc | Zn | 0.2 Max |
| Titanium | Ti | 0.15 Max |
| Others | - | 0.05 Max |
