Triumph Metallic Overseas is a leading name in the industry, recognized as one of the top manufacturers, suppliers, stockists, and exporters of Aluminium Grade 6063 flat bars. Known for its excellent properties, this alloy is widely used in various structural and architectural applications. Our commitment to quality and customer satisfaction ensures that our clients receive only the best products that meet their specifications.
Aluminium Grade 6063 is renowned for its exceptional corrosion resistance and high strength-to-weight ratio. These flat bars are designed to withstand harsh environments while maintaining their structural integrity. Ideal for use in the construction of architectural frameworks, windows, and doors, the lightweight nature of 6063 aluminium makes it easy to handle and install, which is a significant advantage for construction projects.
At Triumph Metallic Overseas, we take pride in our state-of-the-art manufacturing processes that adhere to international quality standards. Our team of experts ensures that each flat bar is produced with precision and care, resulting in a product that meets the diverse needs of our clients. As trusted suppliers and stockists, we maintain a comprehensive inventory of Aluminium Grade 6063 flat bars in various sizes and specifications to ensure prompt delivery and availability for all your project requirements.
Aluminium Grade 6063 Flat Bars Specifications
| Property | Value |
|---|---|
| Alloy | 6063 |
| Temper | T5, T6 |
| Density | 2.68 g/cm³ |
| Tensile Strength | 240 MPa (T5), 310 MPa (T6) |
| Yield Strength | 160 MPa (T5), 270 MPa (T6) |
| Elongation | 10% (T5), 8% (T6) |
| Modulus of Elasticity | 69 GPa |
| Thermal Conductivity | 200 W/m·K |
| Electrical Conductivity | 30 % IACS |
| Corrosion Resistance | Good |
| Applications | Architectural applications, window frames, and structural components |
Aluminium Grade 6063 Flat Bars Equivalent Grades
| Aluminium Grade 6063 | Equivalent Grades |
|---|---|
| 6063 | BS EN 573-3: 6063, 6060 |
| ASTM: 6063, 6060 | |
| DIN: AlMgSi0.5 | |
| EN AW-6063 | |
| ISO: AlMg0.7Si |
Aluminium Grade 6063 Flat Bars Chemical Composition (%)
| Element | Chemical Symbol | Composition Range (%) |
|---|---|---|
| Aluminium | Al | 97.0 - 98.7 |
| Silicon | Si | 0.2 - 0.6 |
| Iron | Fe | 0.35 max |
| Copper | Cu | 0.1 - 0.2 |
| Manganese | Mn | 0.1 max |
| Magnesium | Mg | 0.45 - 0.9 |
| Zinc | Zn | 0.1 max |
| Titanium | Ti | 0.1 max |
| Other Elements | Other | 0.15 max |
